Factory OEM Mobile WiFi Router Pocket WiFi Hotspot 4G LTE Wireless Router with SIM Card Slot Big Battery 4G Mobile Pocket WiFi Router
FeatureDescriptionComplianceNotesBasical InformationModel NameMF833 Form FactorMobile WiFi Dimension93.6*59.5*14.8mm Weightabout 80g Color White or Black ,color can be customized Launch time(PP)2017.2 ID&MD Model Bitmap Bitmap SolutionWireless chipset supplierSanechipYes Routing and WiFi......
Send Inquiry
Product Description
| Feature | Description | Compliance | Notes | |
| Basical Information | Model Name | MF833 | ||
| Form Factor | Mobile WiFi | |||
| Dimension | 93.6*59.5*14.8mm | |||
| Weight | about 80g | |||
| Color | White or Black ,color can be customized | |||
| Launch time(PP) | 2017.2 | |||
| ID&MD Model | Bitmap Bitmap | |||
| Solution | Wireless chipset supplier | Sanechip | Yes | |
| Routing and WiFi chipset supplier | Realtek | Yes | ||
| Baseband | Wireless Chipset | ZX297520V3 | Yes | |
| Wireless Processor | Cortex-R7 | Yes | ||
| Wireless Processor speed | Cortex-R7 @833MHz | Yes | ||
| Routing and WiFi chipset model | Realtek8192ES | Yes | ||
| USIM/SIM Slot | Standard 6 PIN SIM card interface 3V SIM card and 1.8V SIM card | Yes | ||
| Memory(DDR/NAND) | 128MBytes/128MBytes | Yes | ||
| MICRO SDHC Slot | Micro SDHC,2G~32GByte Capacity,SD 2.0 Class 6 | Yes | ||
| USB Version | USB 2.0 HIGH SPEED | Yes | ||
| Interface | USB and Wifi | Yes | ||
| LED indicator | 3 LED indicators WiFi indicator, Network indicator, Battery Indicator | Optional | we support both LED and LCD | |
| RF | Chipset | IRIS405 D Version | Yes | |
| Receive Diversity | Yes | |||
| Equalization | Yes | |||
| Main Antenna | Internal | Yes | ||
| Receive Diversity Antenna | Internal | Yes | ||
| UMTS Band | Band 1/2/4/5/8 | Yes | Optional | |
| TDD B40 or 38/41 | Optional | |||
| LTE band | FDD B1/2/3/4/5/7/8/12 or 13/17/20/28(A+B) | Yes | Optional | |
| Max. transmitter power | LTE: +23dBm (Power Class 3) WCDMA/HSDPA 2100MHz:+24dBm (Power Class 3) GSM/GPRS 850M/900MHz:+33dBm (Power Class 4) GSM/GPRS 1800MHz/1900MHz:+30dBm (Power Class 1) EDGE 850M/900MHz:+27dBm (Power Class E2) EDGE 1800MHz/1900MHz:+26dBm (Power Class E2) | Yes | ||
| WiFi band | 2400MHz-2483.5MHz | Yes | ||
| MIMO for WiFi | 2.4G 802.11.b/g/n MIMO 2*2 | |||
| Technical Standard | GSM/EDGE/WCDMA | GSM CS: UL 9.6kbps/DL 9.6kbps GPRS: Multi-slot Class 10 EDGE: Multi-slot Class 12 WCDMA CS: UL 64kbps/DL 64kbps WCDMA PS: UL 384kbps/DL 384kbps | Yes | |
| HSDPA/HSUPA/HSPA+/LTE | FDD-LTE (CAT 4): Max 150Mbps(DL)/50Mbps(UL) TDD-LTE (CAT 4): Max 130Mbps(DL)/35Mbps(UL) HSPA: Max 21.6Mbps(DL)/5.76Mbps(UL) WCDMA: Max 384kbps(DL)/384kbps(UL) EDGE: Max 236.8kbps(DL)/236.8kbps(UL) GPRS: Max 85.6kbps(DL)/85.6kbps(UL) | Yes | ||
| WiFi Max Station Number | 10 | Yes | ||
| Wi-Fi Standard | 802.11 b/g/n(2*2 ) | Yes | ||
| WiFi Security | WPA/WPA2 | Yes | ||
| 3GPP Release | LTE Rel9, WCDMA R99,R5,R6,R7 | Yes | ||
| OS | Windows XP SP3 later | Yes | ||
| Windows Vista | Yes | |||
| Windows 7 | Yes | |||
| Windows 8/8.1 | Yes | |||
| MAC | Yes | |||
| Linux | No | |||
| Browser | IE | Yes | ||
| Firefox | Yes | |||
| Safari | Yes | |||
| Opera | Yes | |||
| Chrome | Yes | |||
| GPRS Class | Class B | Yes | ||
| Router | DHCP | Yes | ||
| Port Forwarding | Yes | |||
| IP(port) filter/MAC filter | Yes | |||
| URL content filter | No | |||
| DMZ | Yes | |||
| UPnP | Yes | |||
| WPS | PBC(Push Button Config) | Yes | Via WEB-UI page display | |
| Naming Service | Support DNS Relay for LAN side clients | Yes | ||
| RNDIS/ECM | Yes | |||
| SMS | Yes | |||
| STK | Yes | |||
| USSD | Yes | |||
| Phonebook | Yes | |||
| NETWORK LOCK | Optional | |||
| Language | English by default | Yes | ||
| IPv6 | Yes | |||
| FW upgrade | Yes | |||
| Envionment | Operating Temperature | -10 to 60° C | Yes | |
| Storage Temperature | -40 to 70° C | Yes | ||
| Humidity | 5% to 95% | Yes | ||
| Artwork | USB Interface Type | Micro USB | Yes | |
| User manual | Optional | |||
| Warranty cards | Optional | |||
| Battery | NA | |||
| USB cable | Yes | |||
