Poe Injector/Extender Two-in-One 10/100Mbps Wall Mounted
POE Injector/Extender Two-in-one 10/100/1000Mbps1. Work as POE injector, need a 52V 0.6A power supply2. Work as POE extender, can get power from POE uplink then POE extend up to 150m 100Mbps3. Use in pair, one works as POE injector and One works as POE extender, max up to 450m Ethernet transmission.......
Send Inquiry
Product Description
POE Injector/Extender Two-in-one 10/100/1000Mbps
1. Work as POE injector, need a 52V 0.6A power supply
2. Work as POE extender, can get power from POE uplink then POE extend up to 150m 100Mbps
3. Use in pair, one works as POE injector and One works as POE extender, max up to 450m Ethernet transmission. (network Switch -POE injector-POE Extender-terminal device)
1. Work as POE injector, need a 52V 0.6A power supply
2. Work as POE extender, can get power from POE uplink then POE extend up to 150m 100Mbps
3. Use in pair, one works as POE injector and One works as POE extender, max up to 450m Ethernet transmission. (network Switch -POE injector-POE Extender-terminal device)
| Model | EXT101PG |
| Product | Single port Gigabit Poe network injector/ extender(2 in 1) |
| Supporting instructions | Use with POE switch or POE injector or in pair |
| Fixed port | 1*10 / 100/1000M RJ45 Poe power receiving input port 1*10 / 100/1000M RJ45 Poe power supply output ports |
| Poe In port | Support ieee802.3af/at Poe in MAX 30W; (optional Poe + + / BT,MAX65W) Support 40-57v passive Poe in |
| PoE Pin | 1245+ 3678- |
| Poe extender distance | Poe in+ Poe out 10/100/1000M type, max distance 150+150 meters, max power out 30W |
| Supporting power supply | 1: default configuration is no power 2: Optional 12V 0.5A power as network extender 3: Optional 52V 0.6A power can be used as a single port Poe injector |
| Watt | Standby Power Consumption:≤0.5W |
| DC Input | As Network Extender: DC12V MAX 0.5A As PoE Network Extender :DC37-57V MAX 0.6A |
| LED Indicator | Link: Lan network on Speed: Lan speed 100M |
| Network Protocol | Supports IEEE 802.3az-2010 (EEE) 1000BASE-T IEEE 802.3ab 100Base-TX IEEE 802.3u Compliant 10Base-T IEEE 802.3 Compliant IEEE 802.3af/at |
| Transmission Mode | Direct forwarding (full wirespeed) |
| Operating Temperature/Humidity | -10~+55°C;5%~90% RH Non coagulation |
| Storage Temperature/Humidity | -40~+75°C;5%~95% RH Non coagulation |
| Product size(L*W*H) | 112mm*41mm*26mm |
| N.W/G.W(kg) | 0.15kg(1 pairs) |
| Installation | Desktop, wall mounted |
| Lightning protection level | 3KV 8/20us; IP30 |
| Certificate | CE mark, commercial;CE/LVD EN60950; FCC Part 15 Class B;RoHS; |
| Warranty | Whole device for 1 year(Accessories not included) |
