              CISCO CATALYST 2960X-48FPD-L - SWITCH - 48 PORTS - MANAGED - RACK-MOUNTABLESMARTNET ELIGIBLE AND CLEAN SERIALS,MAIN SPECIFICATIONSProduct DescriptionCisco Catalyst 2960X-48FPD-L - switch - 48 ports - managed - rack-mountableDevice TypeSwitch - 48 ports - managed - stackableEnclosure TypeRack-mountab......

              Send Inquiry

              Product Description



              CISCO CATALYST 2960X-48FPD-L - SWITCH - 48 PORTS - MANAGED - RACK-MOUNTABLE

              SMARTNET ELIGIBLE AND CLEAN SERIALS,

              MAIN SPECIFICATIONS
              Product DescriptionCisco Catalyst 2960X-48FPD-L - switch - 48 ports - managed - rack-mountable
              Device TypeSwitch - 48 ports - managed - stackable
              Enclosure TypeRack-mountable 1U
              SubtypeGigabit Ethernet
              Ports48 x 10/100/1000 (PoE+) + 2 x 10 Gigabit SFP+
              Power Over Ethernet (PoE)PoE+
              PoE Budget740 W
              PerformanceSwitching capacity: 216 Gbps ¦ Forwarding performance (64-byte packet size): 130.9 Mpps
              CapacityVirtual interfaces (VLANs): 1023
              Jumbo Frame Support9216 bytes
              Remote Management ProtocolSNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, CLI
              FeaturesLayer 2 switching, DHCP support, power over Ethernet (PoE), auto-negotiation, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Intrusion Detection System (IDS), IPv6 support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, RADIUS support, SSH support, Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), PoE+, Cisco EnergyWise technology, Unicast Reverse Path Forwarding (URPF), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), IPv4 support, Shaped Round Robin (SRR), Link Aggregation Control Protocol (LACP), MAC Address Notification, Remote Switch Port Analyzer (RSPAN), NetFlow, Hot Standby Router Protocol (HSRP) support, Energy Efficient Ethernet, Multicast VLAN Registration (MVR), Class of Service (CoS), Cisco FlexStack Plus
              Compliant StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX
              PowerAC 120/230 V (50/60 Hz)
              Power RedundancyOptional

              EXTENDED SPECIFICATIONS
              General
              Device TypeSwitch - 48 ports - managed - stackable
              Enclosure TypeDesktop, rack-mountable 1U
              SubtypeGigabit Ethernet
              Ports48 x 10/100/1000 (PoE+) + 2 x 10 Gigabit SFP+
              Power Over Ethernet (PoE)PoE+
              PoE Budget740 W
              PerformanceSwitching capacity: 216 Gbps ¦ Forwarding performance (64-byte packet size): 130.9 Mpps
              CapacityVirtual interfaces (VLANs): 1023
              Jumbo Frame Support9216 bytes
              Max Units In A Stack8
              Remote Management ProtocolSNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, CLI
              Authentication MethodKerberos, Secure Shell (SSH), RADIUS, TACACS+
              FeaturesLayer 2 switching, DHCP support, power over Ethernet (PoE), auto-negotiation, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Intrusion Detection System (IDS), IPv6 support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, RADIUS support, SSH support, Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), PoE+, Cisco EnergyWise technology, Unicast Reverse Path Forwarding (URPF), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), IPv4 support, Shaped Round Robin (SRR), Link Aggregation Control Protocol (LACP), MAC Address Notification, Remote Switch Port Analyzer (RSPAN), NetFlow, Hot Standby Router Protocol (HSRP) support, Energy Efficient Ethernet, Multicast VLAN Registration (MVR), Class of Service (CoS), Cisco FlexStack Plus
              Compliant StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX
              Processor: 600 MHz
              RAM512 MB
              Flash Memory128 MB
              Status IndicatorsPort status, port transmission speed, port duplex mode, system, RPS (Redundant Power Supply), PoE, link/activity
              Expansion / Connectivity
              Interfaces48 x 1000Base-T 10Base-T/100Base-TX/1000Base-T - RJ-45 - RJ-45 24 ports (PoE+) / 48 ports (PoE) - 30 W ¦ 1 x console console - RJ-45 - RJ-45 ¦ 1 x mini-USB console - mini-USB Type B - Type B management ¦ 2 x USB Type A ¦ 1 x 1000Base-TX 10Base-T/100Base-TX - RJ-45 - RJ-45 management ¦ 2 x SFP+ - SFP+ uplink
              Expansion Slots1 (total) / 1 (free) x Stacking Module slot
              Power
              Power DeviceInternal power supply
              Power RedundancyOptional
              Voltage RequiredAC 120/230 V (50/60 Hz)
              FeaturesRedundant Power System (RPS) connector
              Miscellaneous
              MTBF233,370 hours
              Compliant StandardsCISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, RoHS, FCC CFR47 Part 15, UL 60950-1 Second Edition, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, Directive 2011/65/EU, VCCI Class A, KN24, KN22 Class A, EN 300386
              Software / System Requirements
              Software IncludedCisco IOS LAN Base
